Biomass steam boiler parameter table

2019-11-21

Technical parameters of heating domestic hot water dual-purpose biomass steam boiler

The biomass steam boiler parameter table is at the bottom of the document.

————————————————– —————————————–

Biomass steam boiler model: ZRZ-30

Biomass steam boiler rated power: 350 kW

Biomass steam boiler heating water: 10 cubic meters

Biomass steam boiler heating working pressure: 0.015 MPa

Biomass steam boiler heating hot and cold water pipe diameter: 50 mm

Biomass steam boiler domestic hot water production: 5 cubic meters

Biomass steam boiler domestic hot water working pressure: 0.010 MPa

Biomass steam boiler domestic hot water hot and cold water pipe diameter: 40 mm

————————————————– —————————————–

Biomass steam boiler model: ZRZ-60

Biomass steam boiler rated power: 695 kW

Biomass steam boiler heating water: 20 cubic meters

Biomass steam boiler heating working pressure: 0.022 MPa

Biomass steam boiler heating hot and cold water pipe diameter: 65 mm

Biomass steam boiler domestic hot water production: 10 cubic meters

Biomass steam boiler domestic hot water working pressure: 0.017 MPa

Biomass steam boiler domestic hot water hot and cold water pipe diameter: 50 mm

————————————————– —————————————–

Biomass steam boiler model: ZRZ-90

Biomass steam boiler rated power: 1050 kW

Biomass steam boiler heating water: 30 cubic meters

Biomass steam boiler heating working pressure: 0.026 MPa

Biomass steam boiler heating hot and cold water pipe diameter: 80 mm

Biomass steam boiler domestic hot water production: 15 cubic meters

Biomass steam boiler domestic hot water working pressure: 0.021 MPa

Biomass steam boiler domestic hot water hot and cold water pipe diameter: 65 mm

————————————————– —————————————–

Biomass steam boiler model: ZRZ-120

Biomass steam boiler rated power: 1390 kW

Biomass steam boiler heating water: 40 cubic meters

Biomass steam boiler heating working pressure: 0.028 MPa

Biomass steam boiler heating hot and cold water pipe diameter: 100 mm

Biomass steam boiler domestic hot water production: 20 cubic meters

Biomass steam boiler domestic hot water working pressure: 0.023 MPa

Biomass steam boiler domestic hot water hot and cold water pipe diameter: 65 mm

————————————————– —————————————–

Biomass steam boiler model: ZRZ-180

Biomass steam boiler rated power: 2100 kW

Biomass steam boiler heating water: 60 cubic meters

Biomass steam boiler heating working pressure: 0.032 MPa

Biomass steam boiler heating hot and cold water pipe diameter: 125 mm

Biomass steam boiler domestic hot water production: 30 cubic meters

Biomass steam boiler domestic hot water working pressure: 0.027 MPa

Biomass steam boiler domestic hot water hot and cold water pipe diameter: 65 mm

————————————————– —————————————–

Biomass steam boiler model: ZRZ-240

Biomass steam boiler rated power: 2780 kW

Biomass steam boiler heating water: 80 cubic meters

Biomass steam boiler heating working pressure: 0.032 MPa

Biomass steam boiler heating hot and cold water pipe diameter: 150 mm

Biomass steam boiler domestic hot water production: 40 cubic meters

Biomass steam boiler domestic hot water working pressure: 0.029 MPa

Biomass steam boiler domestic hot water hot and cold water pipe diameter: 65 mm
