Model of 35 tons biomass fluidized bed boiler: YLW35-1.25-T

1. Rated evaporation: 35

2. Rated steam pressure: 1.25

3. Rated steam temperature: 194

4. Boiler feed water temperature: 105

5. Design fuel: straw, rice husk, aldehyde residue, palm husk, wood, lees, cotton stalk and other biomass

6. Supervision inspection mark CS

7. Initial

8. Smoke exhaust temperature: 145 ℃

9. Boiler design efficiency:> 85%

10, fuel: biomass particles

35 tons of biomass fluidized bed boiler supporting equipment table

Chemical water supply system: soft water, desalinated water system, deaerator, feed water pump, water tank, ammonia adding device, medicine adding device

Steam (hot water) system: steam (water) cylinder, desuperheater

Fuel supply system: coal loading machine, belt coal conveyor, crusher, vibrating screen electronic belt scale, electromagnetic iron remover, double pear type unloader, coal feeder in front of furnace, etc.

Smoke system: blower, induced draft fan, chimney, etc.

Sewage (steam) system: continuous discharge, fixed discharge, sampler, silencer

Electronic control system: general control, PLC control, DCS control

Other equipment in the boiler room: heat exchange station, circulation pump, decontamination device, etc.

Flue gas purification system: dust collector, desulfurization device, denitration device, etc.

Feed water sampling cooler: 1. Material: A3 steel, serpentine tube (20G) 2, 5kgf / cm2

Vent silencer: 1. Medium: superheated steam; 2. Temperature: 450 ℃; 3. Displacement: 12t / h; 4. Main material: 20G; 5. Silence: 40Db (A)

Primary fan: 1. Flow rate: 29000-36000m3 / h; 2. Pressure: 16000-14000Pa

Motor Y355M-40: 1, power: 250Kw; 2, revolutions: 1400r / min
