15t / h biomass direct-fired boiler in sri-lanka

2020-05-12

Sri-lanka has always been our key market. There are many central heating, steam production, and power generation projects. Biomass raw materials are more abundant than other regions. Customers consult 15t / h biomass direct-fired boilers. According to preliminary judgment, the biomass boiler purchased by the customer is used to generate electricity.
Technical Parameters:

Model specification: SZL-15 / 9.8-T

Rated evaporation: 15t / h

Rated steam pressure: 9.8MPA

Rated steam temperature: 540 ℃

Boiler feed water temperature: 215 ℃

Design fuel: straw, rice husk, sugar aldehyde residue, palm husk, wood, lees, cotton stalk and other biomass


Auxiliary equipment

Chemical water supply system: soft water, desalinated water system, deaerator, feed water pump, water tank, ammonia adding device, medicine adding device

Steam (hot water) system: steam (water) cylinder, desuperheater

Fuel supply system: coal loading machine, belt coal conveyor, crusher, vibrating screen electronic belt scale, electromagnetic iron remover, double pear type unloader, coal feeder in front of furnace, etc.

Smoke system: blower, induced draft fan, chimney, etc.

Sewage (steam) system: continuous discharge, fixed discharge, sampler, silencer

Electronic control system: general control, PLC control, DCS control

Other equipment in the boiler room: heat exchange station, circulation pump, decontamination device, etc.

Flue gas purification system: dust collector, desulfurization device, denitration device, etc.
