10t/h biomass steam boiler technical parameters, price and installation size

2020-03-04

What is the price and installation size of a 10t/h biomass steam boiler? Whether it is a boiler price or installation size, it depends on the furnace type. The furnace type is different, the size is naturally different, and the price is also different.

1.DZL biomass steam boiler 10-1.25 / 1.6-T
Evaporation: 10T / H
Working pressure: 1.0 / 1.25 / 1.6 / 2.0 / 2.5MPa
Water temperature: 20/60/105 ℃
Steam temperature: 184/194/204/214/224 ° C
Delivery method: fast loading
Design fuel: biomass particles
Combustion method: chain grate firing
Boiler size: 7745x3773x3441mm
10T / H biomass steam boiler technical parameters, price and installation size


2.SZL biomass steam boiler 10-1.25-T
Rated evaporation capacity: 10t / h
Working pressure: 1.25 / 1.6 / 2.5MPa
Water temperature: 20/60/105 ℃
Steam temperature: 194/204/224 ° C
Heating area of ​​boiler body: 228㎡
Grate area: 11.8㎡
Design fuel: biomass particles
Combustion method: chain grate firing
Boiler size: 7850x3280x3520mm
Large boiler transport weight: 35T


3.SHL biomass steam boiler 10-1.25 / 1.6 / 2.5-T
Evaporation: 10T / H
Working pressure: 1.0 / 1.25 / 1.6MPa
Water temperature: 20/60/105 ℃
Steam temperature: saturated steam
Fuel consumption: 1925kg / h
Design efficiency: 75.3%
Delivery method: bulk
Design fuel: biomass particles
Combustion method: chain grate firing
Boiler size: 11.7×7.2x10m
